Single acting mechanical lock nut hydraulic cylinders/jacks/rams

Quantity:



Inquire Add to Basket

Model:
CLL series

Safety lock nut cylinders for mechanical load holding for up to 1,000 tons

Single-acting, load return

Special synthetic coating for improved corrosion resistance and lower friction for smoother operation

Overflow port functions as a stroke limiter

Interchangeable, hardened grooved saddles are standard

NPT 3/8 coupler and dust cap included on all cylinder models.

Allow for 5° angle loading

QQ截图20140908093917

Model	Capacity @700barton	Stroke (ml)	Effective area (cm²)	oil capacity (cm³)	Closed height (mm) A	Extending height (mm) B	Out diameter (mm) D	Weight (kg)
CLL-502	50	50	71.3	356.5	164	214	125	16
CLL-504		100	71.3	713	214	314	125	21
CLL-506		150	71.3	1069.5	264	414	125	26
CLL-508		200	71.3	1426	314	514	125	31
CLL-5010		250	71.3	1782.5	364	614	125	36
CLL-5012		300	71.3	2139	414	714	125	41
CLL-1002	100	50	133.3	666.5	187	237	165	31
CLL-1004		100	133.3	1333	237	337	165	39
CLL-1006		150	133.3	1999.5	287	437	165	48
CLL-1008		200	133.3	2666	337	537	165	57
CLL-10010		250	133.3	3332.5	387	637	165	65
CLL-10012		300	133.3	3999	437	737	165	74
CLL-1502	150	50	198.0	990	209	259	205	53
CLL-1504		100	198.0	1980	259	359	205	66
CLL-1506		150	198.0	2970	309	459	205	78
CLL-1508		200	198.0	3960	359	559	205	92
CLL-15010		250	198.0	4950	409	659	205	105
CLL-15012		300	198.0	5940	459	759	205	118
CLL-2002	200	50	266.5	1332.5	243	293	235	83
CLL-2006		100	266.5	3997.5	343	493	235	118
CLL-20012		250	266.5	6662.5	443	693	235	153
CLL-2502	250	50	366.4	1832	249	299	275	116
CLL-2506		150	366.4	5496	349	499	275	163
CLL-25010		250	366.4	9160	449	699	275	210
CLL-3002	300	50	457.0	2285	295	345	310	173
CLL-3006		150	457.0	6855	395	545	310	233
CLL-30010		250	457.0	11425	495	745	310	293
CLL-4002	400	50	559.0	2795	335	385	350	251
CLL-4006		150	559.0	8385	435	585	350	327
CLL-40010		250	559.0	13975	535	785	350	403
CLL-5002	500	50	730.0	3650	375	425	400	367
CLL-5006		150	730.0	10950	475	625	400	467
CLL-50010		250	730.0	18250	575	825	400	568
CLL-6002	600	50	857.0	4285	395	445	430	447
CLL-6006		150	857.0	12855	495	645	430	563
CLL-60010		250	857.0	21425	595	845	430	680
CLL-8002	800	50	1179.0	5895	455	505	505	711
CLL-8006		150	1179.0	5895	555	705	505	871
CLL-80010		250	1179.0	29475	655	905	505	1031
CLL-10002	1000	50	1465.0	7325	495	545	560	951
CLL-10006		150	1465.0	21975	595	745	560	1143
CLL-100010		250	1465.0	36625	695	945	560	1335
